QD type hook bridge crane and LH type hoist double-beam crane are relatively common lifting machinery and equipment in the factory at present, and there is no substantial difference between them. QD is a trolley type double-beam bridge crane. The drum, brake, motor and running mechanism motor brake of QD trolley lifting mechanism are installed separately, and are mostly used in occasions with frequent work and harsh environment. LH is a trolley type double-beam bridge crane. The operating mechanism of the lifting mechanism of the electric hoist is integrated into one trolley by the double trolley of the LH hoist. Generally speaking, the size is relatively small. The durability of the LH type trolley is relatively poor than that of the QD type trolley. Guangdong Yongtong Hoisting Machinery Co., Ltd. introduces the difference between QD hook bridge crane and LH hoist double-beam crane.



1、 The essential difference between QD type and LH type:

QD can reach a higher level of work, but LH is difficult to use at a higher level. This is also the fatal weakness of Hulu Shuang. If forced, it can be used, but it will reduce the service life of the equipment. For large tonnage and high working level, double-head hoist is not recommended.




2、 Advantages and disadvantages:

QD: It can bear a strong working level and can be used under more complex and worse working conditions. Easy to maintain. But the price is high, the wheel pressure is large, and the self-weight is heavy.

LH: compact structure, light weight, simple operation and space saving. The disadvantage is that it can't reach a high level of work




3、 Differences between control modes:

Ground operation: handle operation/remote operation. Pneumatic operation: cab (cam control, linkage control)

1. Handle: people follow the car, saving people, controlling the driving and hanging objects. Disadvantages: It is dangerous for people to walk with lifting objects

2. Remote control: It is not necessary to follow the traffic flow when lifting large and dangerous goods. Disadvantages: limited vision.

3. Air movement: wide operation vision. Disadvantages: It is operated by a specially-assigned person and requires the cooperation of the following personnel.
